Deif GPC-3 User Manual

Parameter access
To gain access to adjust the parameters, the password level must be entered:
If the password level is not entered, it is not possible to enter the parameters.
The customer password can be changed in menu 9116.
The service password can be changed in menu 9117.
The master password can be changed in menu 9118.
The factory passwords must be changed, if the operator of the genset is not allowed to change
the parameters.
It is not possible to change the password at a higher level than the password entered.
ML-2 operators manual 4189340579 UK Menu systems and structure
DEIF A/S Page 22 of 29

Deif GPC-3 Specifications

General

Model	GPC-3
Protection front	IP65
Power consumption	10 W
Operating temperature	-20°C to +55°C
Storage temperature	-40°C to 85°C
Communication	Ethernet
Display	Graphical LCD
Dimensions	144 x 144 x 115 mm
