Deif GPC-3 User Manual

2. Display unit
2.1 General
This chapter deals with the display unit including the push-button and LED functions.
2.2 Display (DU-2) layouts
The display dimensions are H × W = 115 × 220 mm (4.528” × 9.055”).
2.2.1 GPC
GPC – standard
Generator Paralleling Controller
multi-line GPC
Self check
Ready
Regulator on
JUMP
INFO
Alarm
VIEW
LOG
REMOTE
LOCAL
BACK
Open
Closed
Power
GPC – options M4 and Y1
Generator Paralleling Controller
multi-line GPC
Self check
Ready
Regulator on
JUMP
START
INFO
STOP
Alarm
VIEW
LOG
REMOTE
LOCAL
BACK
G
Open
ClosedRun
Power
