8. Remove the four screws that secure the power supply to the bezel.
9. Remove the bezel from the power supply.
Replacing the Power Supply
1. Follow the instructions in Before You Begin.
2. Align the screw holes on the power supply with the screw holes on the bezel.
3. Replace the four screws that secure the power supply to the bezel.
4. Slide the power supply into the chassis through the back of the computer.
5. Tighten the four captive screws that secure the power supply to the back of the chassis.
6. Connect the DC wire harness to the power supply.
7. Align the notch on the power-supply cover with the tab on the chassis.
8. Slide the power-supply cover towards the tabs until it locks in place.
9. Replace the left side-panel (see Replacing the Left Side-Panel).
10. Connect your computer and all attached devices to electrical outlets, and turn them on.
Back to Contents Page
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
