Shrouds
Alienware Aurora Service Manual
Opening the PCI Shroud
Closing the PCI Shroud
Removing the Drive-Bay Shroud
Replacing the Drive-Bay Shroud
Opening the PCI Shroud
1. Follow the instructions in Before You Begin.
2. Remove the left side-panel (see Removing the Left Side-Panel).
3. Press the shroud button and rotate the PCI shroud away from the chassis.
Closing the PCI Shroud
1. Follow the instructions in Before You Begin.
2. Lower the PCI shroud into the chassis until it clicks into place.
3. Replace the left side-panel (see Replacing the Left Side-Panel).
4. Connect your computer and all attached devices to electrical outlets, and turn them on.
Removing the Drive-Bay Shroud
1. Follow the instructions in Before You Begin.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
WARNING: Do not operate your computer with any cover(s) (including computer panels, bezels, filler brackets, etc.) removed.
WARNING: To guard against likelihood of electric shock, laceration by moving fan blades, or other unexpected injuries, always unplug your
computer from the electrical outlet before removing the side panel(s).
CAUTION: Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell is
not covered by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
