WiFi/Bluetooth Assembly
Alienware Aurora Service Manual
Removing the WiFi/Bluetooth Card
Replacing the WiFi/Bluetooth Card
Removing the WiFi/Bluetooth Card
1. Follow the instructions in Before You Begin.
2. Remove the left side-panel (see Removing the Left Side-Panel).
3. Open the PCI shroud (see Opening the PCI Shroud).
4. Remove the drive-bay shroud (see Removing the Drive-Bay Shroud).
5. Disconnect the WiFi/Bluetooth assembly cable from the connector on the master I/O board.
6. Loosen the thumbscrew that secures the WiFi/Bluetooth assembly to the chassis.
7. Slide and pull the WiFi/Bluetooth assembly away from the chassis.
For Alienware Aurora/Aurora R2/Aurora ALX
For Alienware Aurora R3
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
WARNING: Do not operate your computer with any cover(s) (including computer panels, bezels, filler brackets, etc.) removed.
WARNING: To guard against likelihood of electric shock, laceration by moving fan blades, or other unexpected injuries, always unplug your
computer from the electrical outlet before removing the side panel(s).
CAUTION: Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell is
not covered by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
NOTE: The WiFi/Bluetooth assembly is available on your computer only if you ordered it while purchasing your computer.
