Replacing the WiFi/Bluetooth Card
1. Follow the instructions in Before You Begin.
2. Align the tab on the WiFi/Bluetooth assembly with the slot on the chassis.
3. Tighten the thumbscrew that secures the WiFi/Bluetooth assembly to the chassis.
4. Connect the WiFi/Bluetooth assembly cable to the connector on the master I/O board.
5. Replace the drive-bay shroud (see Replacing the Drive-Bay Shroud).
6. Close the PCI shroud (see Closing the PCI Shroud).
7. Replace the left side-panel (see Replacing the Left Side-Panel).
8. Connect your computer and all attached devices to electrical outlets, and turn them on.
Back to Contents Page
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
