Removing the M.2 2280 solid-state drive
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
About this task
NOTE: This procedure applies only to computers shipped with a M.2 2280 solid-state drive installed in the following M.2 card
slots:
● M.2 card slot 1
● M.2 card slot 2
The following image(s) indicate the location of the M.2 2280 solid-state drive and provides a visual representation of the removal
procedure.
M.2 2280 solid-state drive in M.2 card slot 1
M.2 2280 solid-state drive in M.2 card slot 2
24
