Installing the palmrest
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the palmrest and provides a visual representation of the installation procedure.
Steps
To install the palmrest perform the post-requisites.
Next steps
1. Install the keyboard.
2. Install the power-button assembly.
3. Install the
power-adapter port.
4. Follow the procedure from step 3 to step 24 in Installing the system board.
5. Install the right I/O-board.
6. Install the keyboard-controller board.
7. Install the touchpad.
8. Install the
speakers.
9. Install the display assembly.
10.Install the rear I/O-cover.
11. Install the M.2 2230 solid-state drive, if applicable.
12. Install the M.2 2280 solid-state drive, if applicable.
13. Install the battery.
14. Install the base cover.
15.Follow the procedure in After working inside your computer.
71
