5. Remove the M.2 2280 solid-state drive, if applicable.
6. Remove the rear I/O-cover.
7. Remove the speakers.
8. Remove the right I/O-board.
9. Follow the procedure from step 1 to step 19 in
Removing the system board.
10.Remove the power-adapter port.
About this task
NOTE: This procedure is only applicable for computers shipped with a mechanical keyboard.
The following image(s) indicate the location of the keyboard and provides a visual representation of the removal procedure.
66
