Dell Chromebook 5190 2-in-1 User Manual

Installing WLAN card
Steps
1. Insert the WLAN card into the slot on the system.
2. Connect the WLAN antenna cables to the connectors on the WLAN card.
3. Place the WLAN card bracket to secure the WLAN cables to the WLAN card.
4. Replace the single (M2x3) screw to secure the WLAN card bracket to the system.
5. Install the:
a. battery
b. base cover
c. microSD card
6. Follow the procedure in After working inside your computer.
18
Removing and installing components

Dell Chromebook 5190 2-in-1 Specifications

General

RAM	4GB LPDDR4
Storage	32GB eMMC
Graphics	Intel HD Graphics 500
Operating System	Chrome OS
Battery Life	Up to 10 hours
Weight	1.44 kg (3.17 lbs)
Wireless	802.11ac Wi-Fi, Bluetooth 4.2
Display	11.6-inch HD (1366 x 768) IPS Touch Display
Ports	MicroSD card reader, headphone/microphone combo jack
Camera	720p HD webcam
Battery	3-Cell 42 WHr Battery
Processor	Intel Celeron N3450
