Dell EMC Core XC750 User Manual

Figure 36. Installing the GPU shroud filler
Next steps
1. If required, install the full length expansion card risers.
2. Install the GPU air shroud top cover.
3. Follow the procedure listed in After working inside your system.
Removing the rear drive module air shroud
Prerequisites
CAUTION:
Never operate your system with the air shroud removed. The system may get overheated quickly,
resulting in shutdown of the system and loss of data.
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system
Steps
Press the edges on either side of the rear drive module air shroud, and lift the rear drive module air shroud out of the rear drive
module.
Installing and removing system components
43
