Jumpers and connectors
This topic provides some basic and specific information about jumpers and switches. It also describes the connectors on the
various boards in the system. Jumpers on the system board help to disable the system and reset the passwords. To install
components and cables correctly, you must know the connectors on the system board.
Topics:
• System board connectors
• System board jumper settings
• Disabling a forgotten password
System board connectors
Figure 182. System board jumpers and connectors
Table 55. System board jumpers and connectors
Item Connector Description
1. LFT_CP Left control panel connector
2. BAT_SIG NVDIMM battery signal
7
Jumpers and connectors 169
