Applying PDU labels, VMAX 250F
Procedure
1. Locate and complete the PDU label.
2. Place the label on the bottom, inner surface of the PDU enclosure for side A and
B.
Figure 45 Applying the PDU labels
Rear view
Example shown:
2 V-Bricks
PDP
1010
A
B
1010
A
B
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
PDU
40U rack
PDP
PDU
Power zone A
(right, gray)
Power zone B
(left, black)
(Power zone B)
(Power zone B)
(Power zone A)
(Power zone A)
046-003-593_A02
Power Zone B Power Zone A
Customer PDU
Information
PDU
Panel
CB’s
PDU
Panel
CB’s
(Add label to bottom,
inside surface of PDU)
(Add label to bottom,
inside surface of PDU)
PDU label
(not to scale)
Best Practices for AC Power Connections
