Installing the Hardware 31
E600i ExaScale Chassis Physical Design
Maximum AC Power Supply Input 16 A @ 100 VAC per module
12 A @ 200 VAC per module
Maximum Thermal Output (3,172 W)
Maximum Thermal Output (2,906 W)
10,822 BTU/hour at 100/120 VAC
9,914 BTU/hour at 200/240 VAC
Maximum AC Supply Input Current
(based on 2500 W output for 100/120V
and 200/240V lines.)
11.6 A @ 100 VAC
9.7 A @ 120 VAC
8.0 A @ 200 VAC
6.7 A @ 240 VAC
Maximum System Power Input 3.5 KVA @ 100/120 VAC
3.2 KVA @ 220/240 VAC
Maximum Power Consumption 3,422 W at 100/120 VAC
3,156 W at 200/240 VAC
Parameter Specifications
Height 28 inches (71.1 cm)
Width 17.4 inches (44.2 cm)
Depth (without cable management
system)
21.5 inches (54.6 cm)
Chassis weight with factory-installed
components (backplane and air filter)
81 pounds (36.7 kg)
Weight fully loaded (backplane, air
filter, fan tray, SFMs, RPMs, and 7 line
cards)
242 pounds (109.8 kg)
Maximum Thermal Output
NOTE: Thermal output is directly proportional to system configuration and
number of line cards.
Parameter Specifications
