Installing the S4820T
To install the S4820T system, Dell Force10 recommends completing the installation procedures in the
order presented in this chapter.
Always handle the S4820T and its components with care. Avoid dropping the system or its Field
Replaceable Units (FRUs).
This chapter describes the installation procedures as follows:
1 Unpacking the S4820T Switch
2 Installing Rack or Cabinet Hardware
a Installing the Dell ReadyRails System
b Two-post Flush-mount Configuration
c Two-post Center-mount Configuration
d Four-post Threaded Configuration
3 Installing the S4820T Switch
a 1U Front-rack Installation
b Attaching the Ground Cable
c Installing an AC or DC Power Supply
4 Installing QSFP+ Optics
5 Connecting the Stacking Ports (Optional)
6 Powering Up the S4820T Switch
WARNING: Electrostatic discharge (ESD) damage can occur if components are mishandled. Always wear an
ESD-preventive wrist or heel ground strap when handling the S4820T and its components. As with all
electrical devices of this type, take all the necessary safety precautions to prevent injury when installing this
system.
Unpacking the S4820T Switch
NOTE: Before unpacking the switch, inspect the container and immediately report any evidence of damage.
Package Contents
When unpacking each S4820T switch, make sure that the following items are included:
• One S4820T switch
• One RJ-45 to DB-9 female cable
• Two sets of rail kits (no tools required)
