Dell Force10 Software Defined Networking User Manual

Usage
Information
This is a vendor-specific CLI.
Related
Commands
openflow of-instance Create or modify an OpenFlow instance.
of-instance (Interface)
Add a physical interface or LAG to an OpenFlow instance.
Z-Series, S4810
Syntax
of-instance of-id
Parameter
of-id Enter the OpenFlow instance ID. Range is 1 to 8.
Command Modes INTERFACE MODE
Command History
Version 9.1(0.0) Introduced on Z9000 and S4810.
Example In the following example, the ports Te 0/7 and Te 0/31 are associated with of-instance 1:
FTOS(conf)#interface tengigabitethernet 0/7
FTOS(conf-if-te-0/7)#of-instance 1
FTOS(conf-if-te-0/7)#interface tengigabitethernet 0/31
FTOS(conf-if-te-0/31)#of-instance 1
FTOS(conf-if-te-0/31)#
Usage
Information
To enable OpenFlow, associate a port or a VLAN to an OF instance. Ports and VLANs must be
associated when the OF instance is created and in a “shut” state (shutdown).
LAGs or port-channel interfaces are supported as of-ports or of-vlan members on OpenFlow.
By default, all ports are available for legacy functionality.
The following features are not supported on physical interfaces associated with an OpenFlow
instance:
• Dot1x
• Ethernet
• GVRP
• IPv4
• IPv6
• MAC
• MTU
• Port-channel protocols
• Spanning-tree protocols
• Switchport
The following features are not supported on LAGs associated with an OpenFlow instance:
• Ethernet
32
