Dell Force10 Software Defined Networking User Manual

controller
Specify the OpenFlow controller configuration that the OpenFlow instance uses to establish a connection.
Z-Series, S4810
Syntax
controller {controller-id}{ip-address}[port port-number]tcp
Parameter
controller-id Enter the controller number (must be 1).
ip-address Enter the IP address of the controller.
port port-number Enter the keyword port followed by the port number to use for the
connection. Range is 1 to 65535.
Defaults Default port number for the TCP connection is 6633.
Command Modes OPENFLOW INSTANCE
Command History
Version 9.1(0.0) Introduced on Z9000 and S4810.
Usage
Information
The controller number must be entered as 1 to enable OpenFlow. Currently, only TCP
connection is supported.
Related
Commands
openflow of-instance Create or modify an OpenFlow instance.
debug openflow packets
Enable debugging for OpenFlow packets.
Z-Series, S4810
Syntax
debug openflow packets {packet-type packet-type} of-instance
{of-id}
Parameter
{packet-type
packet-type }
Enter the keyword packet-type followed by one of the following
packet types:
all Enable debugging for all packets.
barrier-reply Enable debugging for barrier-reply packets.
barrier-request Enable debugging for barrier-request
packets.
echo-reply Enable debugging for echo-reply packets.
echo-request Enable debugging for echo-request packets.
error Enable debugging for error packets.
28
