1. Using the alignment posts and rubber grommets, replace the speaker into the slots on the computer chassis.
2. Route the speaker cable through the routing channel.
3. Affix the adhesive tapes to secure the speaker cable on the system board.
4. Connect the speaker cable to the connector on the system board.
1. Install the palmrest and keyboard assembly.
2. Follow the procedure in after working inside your computer.
Coin-cell battery
Removing the coin-cell battery
NOTE:
Removing the coin-cell battery resets the BIOS setup program's settings to default. It is recommended that you
note the BIOS setup program's settings before removing the coin-cell battery.
1. Follow the procedure in before working inside your computer.
2. Remove the palmrest and keyboard assembly.
The following image indicates the location of the coin-cell battery and provides a visual representation of the removal procedure.
Removing and installing components
25
