4. Remove the hard drive from the computer.
Installing the Hard Drive
1. Place the hard drive inside the computer.
2. Place the hard-drive bracket on the hard drive.
3. Tighten the screws to secure the hard drive to the computer.
4. Connect the hard-drive cable to its connector on the system board..
5. Install:
a. base cover
b. battery
6. Follow the procedures in After Working Inside Your computer.
Removing the Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
3. Perform the following steps as shown in the illustration:
a. Disconnect the coin-cell cable from its connector on the system board [1].
b. Pry the coin-cell to remove from the computer [2].
14
