Installing the Display Panel
1. Connect the eDP to its connector on the display panel and affix the adhesive tape.
2. Place the display panel to its original position on the display assembly.
3. Tighten the screws to secure the display panel to the display assembly.
4. Install:
a. display bezel
b. battery
5. Follow the procedures in After Working Inside Your computer.
Removing the Camera
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. display bezel
c. display panel
3. Perform the following steps as shown in the illustration:
a. Disconnect the camera cable from its connector on the display assembly [1].
b. Remove the camera from the display assembly [2].
