4. Perform the following steps as shown in the illustration:
a. Remove the screws that secure the speakers to the computer [1].
b. Remove the speakers from the computer [2].
Installing the Speaker
1. Align the speakers to their original position and tighten the screws to secure the speakers to the
computer.
2. Route the speaker cables to their routing channels on the computer.
3. Connect the speaker cable to its connector on the system board.
4. Install:
a. palmrest
b. keyboard
c. keyboard trim
d. hard drive
e. base cover
f. battery
5. Follow the procedures in After Working Inside Your computer.
26
