Installing the Palmrest
1. Align the palmrest to its original position on the computer until it snaps in its place.
2. Connect the power LED and touchpad cables to their connectors on the system board.
3. Tighten the screws to secure the palmrest to the front of the computer.
4. Flip the computer and tighten the screws to secure the palmrest to the computer.
5. Install:
a. keyboard
b. keyboard trim
c. base cover
d. battery
6. Follow the procedures in After Working Inside Your computer .
Removing the Speakers
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. hard drive
d. keyboard trim
e. keyboard
f. palmrest
3. Perform the following steps as shown in the illustration:
a. Disconnect the speaker cable from its connector on the system board [1].
b. Release the speaker cables from their routing channels [2].
25
