a. system board
b. system fan
c. display assembly
d. WLAN card
e. WWAN card
f. hard drive
g. palmrest
h. keyboard
i. keyboard trim
j. base cover
k. battery
4. Follow the procedures in After Working Inside Your computer.
Removing the Power-Connector Port
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. keyboard trim
d. keyboard
e. palmrest
f. hard drive
g. WWAN card
h. WLAN card
i. hinge cover
j. display assembly
k. camera
l. coincell battery
m. I/O board
n. speakers
o. system fan
p. system board
3. Perform the following steps as shown in the illustration:
a. Remove the screws to release the metal bracket that secure the power-connector port [1].
b. Remove the metal bracket from the power-connector port [2].
c. Remove the power-connector port from the computer chassis [3].
