Dell Latitude E7450 - Removing the System Fan; Installing the System Fan; Removing the Display Bezel

Removing the System Fan
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
3. Perform the following steps as shown in the illustration:
a. Disconnect the system-fan cable from its connector on the system board [1].
b. Remove the screws that secure the system fan to the computer [2].
c. Remove the system fan from the computer [3].
Installing the System Fan
1. Place the system fan into its slot on the computer.
2. Tighten the screws to secure the system fan to the computer.
3. Connect the system-fan cable to the computer.
4. Install:
a. base cover
b. battery
5. Follow the procedures in After Working Inside Your computer.
Removing the Display Bezel
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Pry the edges to release the display bezel from the display assembly.
17
