Option Description
NOTE: SATA is configured to
support RAID mode.
Drives Allows you to configure the SATA drives
on board. The options are:
• SATA-0
• SATA-1
• SATA-2
• SATA-3
Default Setting: All drives are enabled.
SMART Reporting This field controls if the hard-drive
errors for the integrated drives are
reported during system startup. This
technology is part of the SMART (Self
Monitoring Analysis and Reporting
Technology) specification.
• Enable SMART Reporting - This
option is disabled by default.
USB Configuration Allows you to define the USB
configuration. The options are:
• Enable Boot Support
• Enable External USB Port
• Enable USB3.0 Controller
Default Setting: All the options are
enabled.
USB PowerShare Allows you to configure the behavior of
the USB PowerShare feature. The option
is disabled by default.
• Enable USB PowerShare
Audio Allows you to enables or disables the
integrated audio controller.
• Enable Audio—This option is
enabled by default.
Unobtrusive Mode Allows you to set the mode that will turn
off all light and sound emissions from
the system. The option is disabled by
default.
• Enable Unobtrusive Mode
Miscellaneous Devices Allows you enable or disable the various
on board devices. The options are:
• Enable Microphone
• Enable Hard Drive Free Fall
Protection
