Dell Latitude E7450 - Page 55

Table 26. Touchpad
Feature Specification
Active Area:
X-axis 99.5 mm
Y-axis 53.0 mm
Table 27. Battery
Feature Specification
Type
• 3-cell Lithium Polymer battery with ExpressCharge
• 4-cell Lithium Polymer battery with ExpressCharge
Dimensions: Latitude E7450
3–cell/4–cell
Depth 74.75 mm (2.94 inches)
Height 8.00 mm (0.31 inch)
Width 308.50 mm (12.15 inches)
Weight:
3-cell 247.00 g (0.54 lb)
4–cell 308.00 g (0.68 lb)
Temperature range:
Operating
Charge: 0 °C to 50 °C (32 °F to 158 °F)
Discharge: 0 °C to 70 °C ( 32 °F to 122 °F)
Non-Operating –20 °C to 65 °C (4 °F to 149 °F)
Coin-cell battery 3 V CR2032 lithium coin cell
Table 28. AC Adapter
Feature Specification
Type 65 W and 90 W
Input voltage 90 VAC to 264 VAC
Input current (maximum) 1.50 A
Input frequency 47 Hz to 63 Hz
Output power 65 W and 90 W
Output current 3.34 A and 4.62 A
Rated output voltage 19.5 VDC
Weight 230 g (65 W) and 285 g (90 W)
55
