Dell P89G - Page 15

5. Lift the right side and then the left side of the base cover.
NOTE:
The VGA port and the plastic from the base cover, must lift right side (as shown in illustration) up at an angle
then release the left side in order to not get caught on the VGA port and damage either the base cover or VGA port.
Disassembly and reassembly 15
