Removing the power button with ngerprin
t
reader
WARNING
: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in
Before working inside your computer. After working inside your computer, follow the instructions in After working inside
y
our computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/
r
egulatory_compliance.
NOTE
: Applicable only for computers that are shipped with ngerprint reader.
Prerequisites
1 Remove the base cover
.
2 Remove the wireless card
.
3 Remove the fan
.
4 Remove the heat sink.
5 Remove the display assembly.
6 Remove the I/O board.
Procedure
1 Disconnect the ngerprint-reader cable from the system board and peel the ngerprint-reader cable o the palm-rest assembly.
2 Remove the screw (M3x3) that secures the power-button board to the palm-rest assembly.
3 Using a plastic scribe, peel the power-button board from the palm-rest assembly.
4 Lift the power-button board, along with its cable, o the palm-rest assembly.
28
Removing the power button with ngerprint reader 47
