Dell P91G - Chapter 42: Removing the Display Hinges; Prerequisites; Procedure

94 pages

Save Page as PDF

To Next Page

To Previous Page

Post-requisites

1 Follow the procedure from step 4 to step 14 in "Replacing the display panel".

2 Replace the display assembly

3 Replace the heat sink.

4 Replace the fan.

5 Replace the wireless card.

6 Replace the base cover.

76 Replacing the camera
