Removing the battery
WARNING
: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in
Before working inside your computer. After working inside your computer, follow the instructions in After working inside
y
our computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/
r
egulatory_compliance.
Prerequisites
Remove the base cover
.
Procedure
1 Disconnect the battery cable from the system board (applicable only if not disconnected earlier).
2 Remove the speaker cable from the routing guides on the battery.
3 Remove the four screws (M2x3) that secure the battery to the palm-rest assembly.
4 Lift the battery o the palm-rest assembly.
8
Removing the battery 19
