Configuring Link Aggregation 805
hashing-mode mode Set the hashing algorithm on the LAG.
The
mode value is a number from 1 to 7. The numbers
correspond to the following algorithms:
• 1 — Source MAC, VLAN, EtherType, source module, and
port ID
• 2 — Destination MAC, VLAN, EtherType, source
module, and port ID
• 3 — Source IP and source TCP/UDP port
• 4 — Destination IP and destination TCP/UDP port
• 5 — Source/destination MAC, VLAN, EtherType, and
source MODID/port
• 6 — Source/destination IP and source/destination
TCP/UDP port
• 7 — Enhanced hashing mode
CTRL + Z Exit to Privileged EXEC mode.
show interfaces port-
channel [ port-channel
number
]
View LAG information for the specified LAG or for all
LAGs.
show statistics port-
channel port-channel-
number
View interface statistics for the specified LAG.
Command Purpose
