Configuring IP Routing 913
Configuring Router Discovery (IRDP)
Beginning in Privileged EXEC mode, use the following commands to
configure IRDP settings.
Command Purpose
configure Enter global configuration mode.
interface interface Enter interface configuration mode for the specified
VLAN routing interface. The
interface variable includes
the interface type (vlan) and number, for example vlan
100.
ip irdp Enable IRDP on the interface.
ip irdp address ip-address Configure the address that the interface uses to send the
router discovery advertisements.
The allowed addresses are 224.0.0.1 (all-hosts IP
multicast address) or 255.255.255.255 (limited broadcast
address)
ip irdp holdtime
seconds Configure the value of the holdtime field of the router
advertisement sent from this interface.
ip irdp maxadvertinterval
seconds
Configure the maximum time allowed between sending
router advertisements from the interface.
ip irdp minadvertinterval
seconds
Configure the minimum time allowed between sending
router advertisements from the interface.
ip irdp preference integer Configure the preference of the address as a default
router address relative to other router addresses on the
same subnet.
exit Exit to Global Config mode.
exit Exit to Privileged EXEC mode.
show ip irdp [vlan
vlan-id ] View the router discovery information for all interfaces,
or for a specified interface.

Dell PowerConnect 8164F Specifications

General

Enclosure Type	Rack-mountable - 1U
Power Device	Internal power supply
Installed Qty	1
Power Redundancy	Optional
Power Supply	AC 120/230 V (50/60 Hz)
Width	17.3 in
Height	1.7 in
Device Type	Switch
Forwarding Rate	960 Mpps
MAC Address Table Size	128000 entries
Routing Protocol	OSPF, RIP-1, RIP-2, BGP, VRRP, OSPFv3, RIPng
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH-2, CLI
Management	Web based management
Features	Flow control, VLAN support, DHCP support, BOOTP support, port mirroring, IPv6 support, DiffServ support, Weighted Round Robin (WRR) queuing, Access Control List (ACL) support, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Jumbo Frames support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
Jumbo Frame Support	9KB
