Installing System Components 137
Figure 3-25. Installing or Removing an iDRAC6 Enterprise Card (Optional)
6
Install the I/O card. See "Installing the I/O Card" on page 135.
7
Close the system. See "Closing the System" on page 90.
8
Reconnect the system and peripherals to their power sources, and turn
them on.
1 iDRAC6 Enterprise card 2 VFlash media slot
3 retention standoff tabs (2) 4 retention standoff posts (2)
5 iDRAC6 Enterprise card connector
