Connector Description
3 Slot 3 PCIE_G3_X1
PCH
PCIe card connector 3
4 INT_USB_3.0 Internal USB
5 Slot 4 PCIE_G3_X4
PCH
PCIe card connector 4
6 J_INTRU2 Intrusion connector
7 MB / Fan1 Cooling fan connector
8 CPU Processor
9 J_AMEA1 iDRAC ports card connector
10 A1, A2, A3, A4 Memory module sockets
11 CPU_PWR CPU power connector P2
12 SATA 0–3/SATAe Mini SAS connector
13 SATA_ODD/SSD Optical disk drive connector
14 SYS_PWR System power P1
15 PWR_EVNT Power event
16 PWRD_EN Password jumpers
17 J_SATA_2 SATA connector 2
18 NVRAM_CLR NVRAM password jumper
19 TPM Trusted platform module connector
20 PIB_CONN PIB connector
21 IDSDM Internal dual SD module connector
22 HDD/ODD_PWR Hard drive power connector
23 BP_SIG Backplane signal connector
24 FP_USB Front panel USB connector
25 CTRL_PNL Control panel
26 BATTERY System battery
System board jumper settings
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
