Figure 52. Removing and installing the control panel assembly cover for system with LCD panel
Next steps
1. Install the control panel assembly cover.
2. Follow the procedure listed in After working inside your system.
Related Tasks
Removing the control panel assembly
Installing the control panel assembly cover
Preparing a system for conversion from tower mode to rack mode
Installing the control panel assembly cover
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
1. Ensure that you follow the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
1. Align the tabs on the control panel assembly cover with the slots on the control panel.
2. Push the cover until the tabs lock into place.
Next steps
1. Install the control panel assembly.
2. Follow the procedure listed in After working inside your system.
124
