Dell PowerEdge T630 - GPU Cards (Optional); GPU Card Installation Guidelines; Removing an Optional GPU Card

After working inside your system
Removing the optional GPU card holder
GPU cards (optional)
GPU card installation guidelines
Observe the following guidelines while installing a GPU card:
• Ensure that the GPU enablement kit is ready.
• Ensure that all GPU cards are of the same type or model.
• Each GPU card supports up to 6 GB of dedicated GDDR5 memory.
• A single processor configuration only supports up to two double or single width cards on slots 1 and
3.
• A dual processor configuration supports up to four double or single width cards on slots 1, 3, 6, and 7.
• Both the processors must be installed to use slots 6 and 7.
• Two double-width GPU cards on a single processor configuration and four double width GPU cards
on a dual processor configuration do not support any other add-on cards.
• On a system with four double-width GPU cards, the hard-drive setting must be either onboard SATA
controller or S110.
• Four double-width 300 W GPU cards (Intel 3120A or Intel 7120A) on a dual processor configuration or
two double-width 300 W GPU cards (Intel 3120A or Intel 7120A) on a single processor configuration
cannot operate at an ambient temperature above 30 °C.
• The 3.5 inch x18 hard-drive system configuration supports two double-width 300 W GPU cards (Intel
3120A or Intel 7120A) on slots 3 and 6 on dual processor configuration, and one double-width 300 W
GPU card (Intel 3120A or Intel 7120A) on slot 3 on single processor configuration.
• Two single-width GPU cards on a single processor configuration and four single-width GPU cards on
a dual processor configuration do not support H730, H730P, and H830 PERC cards.
• A system with Express Flash configuration supports a maximum of two GPU cards.
• The GPU cards must be installed:
– On the x16 PCIe Generation 3 interfaces available on slots 1, 3, 6, and 7.
– On systems that support one 5.25-inch removable media storage devices.
– On systems with six fan configuration.
– On systems that have 1100 W and 1600 W power supply.
NOTE: When you have more than two GPU cards on your system, you will need two 1100 W
PSUs installed on your system.
NOTE: For Nvidia Tesla m60A GPGPU support, add another adapter cable to fit the M60 Power
pins.
Removing an optional GPU card
Prerequisites
1. Follow the safety guidelines listed in the safety instructions section.
2. Follow the procedure listed in the Before working inside your system section.
3. Remove the cooling shroud.
4. Remove the expansion card holder.
