Table 10. Reset button behavior
Reset button Description LED status
Press for 4 s-> stop-> 8 s. Cold reset is performed. Blinking green at the rate of 256
milliseconds
Press for 8 s-> stop->12 s. A flag is set in the CPLD register for
this partial clean request. The operating
system performs a partial clean of
settings, and sets a reset bit for the
CPLD to perform a cold reboot.
Solid amber
Press for 12 s-> stop. A flag is set in CPLD register for this
complete clean request. The operating
system performs a complete reset of any
user configured parameters and sets a
reset bit for the CPLD to perform a cold
reboot.
Solid green
N3200-ON/E3200-ON Series switch 21
