Page #8 background imageLoading...
Page #8 background image
N3200-ON/E3200-ON Series switch
The following sections describe the Dell N3200-ON/E3200-ON Series (N3208PX-ON, N3224T-ON, N3224F-ON/E3224F-
ON, N3224P-ON, N3224PX-ON, N3248TE-ON, N3248P-ON/E3248P-ON, N3248X-ON, and N3248PXE-ON/E3248PXE-ON)
switches:
Topics:
Introduction
Features
Physical dimensions
LED display
Prerequisites
N3200-ON/E3200-ON Series switch configurations
Luggage tag
N3200-ON/E3200-ON series reset button
Introduction
The N3200-ON/E3200-ON Series switches are compact and full width, one rack unit (RU), full-featured fixed form-factor
switches.
Table 1. N3200-ON/E3200-ON Series switch summary
Marketing model name (MMN) Description Power supply unit (PSU) and fans
N3208PX-ON
Four ports 1G BASE-T RJ45 with
802.3bt Type-4 (90 W) PoE
Four ports 5G BASE-T RJ45
multigigabit ports with 802.3bt
Type-4 (90 W) PoE
Two ports 10G SFP+
One fixed AC PSU
(optional) Up to two external power
adapters
One fixed fan
N3224T-ON
24 ports 1G BASE-T RJ45
Four ports 10G SFP+
Two ports 100G QSFP28 stacking
Two pluggable AC PSUsone
default and one optional or two
optional DC PSUs
Three pluggable fan modules
Normal and reverse airflow options
N3224F-ON/E3224F-ON
24 ports 1G SFP
Four ports 10G SFP+
Two ports 100G QSFP28 stacking
Two pluggable AC PSUsone
default and one optional or two
optional DC PSUs
Three pluggable fan modules
Normal airflow only
N3224P-ON
24 ports 1G BASE-T RJ45 ports with
802.3at (30 W) PoE
Four ports 10G SFP+
Two ports 100G QSFP28 stacking
Two pluggable AC PSUsone
default and one optional or two
optional DC PSUs
Three pluggable fan modules
Normal airflow only
N3224PX-ON
24 ports 10M/100M/1G/
2.5G/5G/10G BASE-T RJ45
multigigabit ports with 802.3bt
Type-4 (90 W) PoE
Four ports 25G SFP28
Two pluggable AC PSUsone
default and one optional or two
optional DC PSUs
1 EPS (optional and connected from
MPS-1S or MPS-3S power shelf)
2
8 N3200-ON/E3200-ON Series switch
