Dell PowerSwitch N3200-ON Series - Management Ports; RJ45 Console Port Access

Management ports
The N3200-ON/E3200-ON Series switch provides two ports for management and one USB flash drive mount for file transfers.
NOTE: The output examples in this section are for reference only. Your output may vary.
Topics:
• RJ45 console port access
• MicroUSB Type-B console port access
• USB storage mount
RJ45 console port access
For the N3200-ON/E3200-ON Series switch, the management ports are on the I/O-side of the switch.
N3208PX-ON management ports
1. Out-of-band management port (right), RJ45 console port (left)
N3224F-ON/E3224F-ON management ports
1. Out-of-band management port (right), RJ45 console port (left)
N3224P-ON, N3224T-ON and N3224PX-ON management ports
8
Management ports 71
