ceiling mount
One RU ReadyRails installation
Install the N3200-ON/E3200-ON Series switch, excluding the N3208PX-ON switch, using one of the following installation
instructions.
You can install the ReadyRails system using the 1U tool-less square-hole method or one of three possible 1U threaded round-hole
methods. The tooled installation methods include two-post flush mount, two-post center mount, or four-post threaded mount.
NOTE: You must order the ReadyRails mounting supplies for this installation separately.
To begin installation, separate each rail assembly by sliding the inside rail out of the outside rail.
NOTE: For more installation instructions, see the installation labels attached to the rail assembly.
N3200-ON/E3200-ON Series switch installation 37
