Power supply
The N3200-ON/E3200-ON Series switch ships with one pluggable AC power supply. You can order a second AC PSU
separately. If you require DC power, you can order one or two DC PSUs.
The N3224PX-ON, N3248P-ON/E3248P-ON, and N3248PXE-ON/E3248PXE-ON switches also support an optional external
power supply that connects to the switch using an MPS-1S or MPS-3S shelf. Use the EPS to add redundancy, or extend
the PoE budget that is based on your requirement. To install an external power supply, see the External Power Supply (EPS)
Installation for the Dell PowerSwitch N2200-ON and N3200-ON/E3200-ON Series Switches at www.dell.com/support.
Table 11. AC PSU input voltage
AC PSU Input voltage Output
DPS-320AP (For N3208PX-ON only)
● Low line = 110 V
● High line = 220 V
● 300 W
● 300 W
DPS-550
● Low line = 110 V
● High line = 220 V
● 550 W
● 550 W
DPS-1050
● Low line = 110 V
● High line = 220 V
● 950 W
● 1050 W
DPS-1600
● Low line = 110 V
● High line = 220 V
● 950 W
● 1600 W
Table 12. DC PSU input voltage
DC PSU Input voltage Output
DPS-550
● -40 V to -60 V ● 550 W
DPS-1300
● -40 V to -60 V ● 1300 W
CAUTION: To prevent electrical shock, ensure that the N3200-ON/E3200-ON Series switch is grounded
properly. If you do not ground your equipment correctly, excessive emissions may result. Use a qualified
electrician to ensure that the power cables meet your local electrical requirements.
WARNING: Equipment that provides DC input to the DC port must be certified for CCC and meet the relevant
standards.
NOTE: Reserve airflow, from the PSU-side to the I/O-side of the switch, is only supported on the N3224T-ON, N3248X-
ON, and N3248TE-ON switches.
NOTE: Connect the power supply to the appropriate branch circuit protection as defined by your local electrical codes.
Verify that the remote power source complies with the switch input power specifications.
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-preventive wrist or heel ground strap
when handling the N3200-ON/E3200-ON Series switch and components.
Topics:
• Components
• AC or DC power supply installation
• AC or DC power supply replacement
• 550W DC power connections
• 1300W DC power connections
• Connect the EPS shelf
6
