NOTE: If you are connecting a single EPS power cable to your switch, always use primary A-slot. Leave the secondary
B-slot DC power cover in place, as shown:
2. Unscrew the DC-power-OUT cover from the rear of the EPS shelf.
NOTE:
If you are connecting a single EPS power cable to your MPS-3S shelf, always use primary A-slot. Leave the
secondary B-slot DC power cover in place.
MPS-1S shelf
MPS-3S shelf
64
Power supply
