Table 15. Power consumption parameters (continued)
Parameter Specifications
● N3248PXE-ON/E3248PXE-ON: 5.44 Amps @ 110 VAC
and 1.72 Amps @ 220 VAC
PSU configuration Main PSU
Maximum steady current consumption
● 7 A@110 VAC
● 3.5 A@220 VAC
PoE output per port
● N3208PX-ON: 4x1G Base-T Ports with 4 ports of 802.3bt
Type-4 (90W) PoE, + 4x5GBase-T Ports with 4 ports of
802.3bt Type-4 (90W) PoE
● N3224P-ON: 24x1G Base-T Ports with 802.3at Type-2
(30W) PoE
● N3224PX-ON: 24x10GBase-T Ports with 802.3bt Type-4
(90W) PoE
● N3248P-ON/E3248P-ON: 48x1G Base-T Ports with
802.3at Type-2 (30W) PoE
● N3248PXE-ON/E3248PXE-ON: 48x10GBase-T Ports with
802.3bt Type-4 (90W) PoE
NOTE: 802.3bt Type-4 can support a minimum of 90 W
and a maximum of 99.99 W at PSE output.
Table 16. AC power requirements
Parameter Specifications
Power supply
● N3208PX-ON: 100–240 VAC 50/60 Hz
● N3224T-ON: 100–240 VAC 50/60 Hz
● N3224F-ON/E3224F-ON: 100–240 VAC 50/60 Hz
● N3224P-ON: 100–240 VAC 50/60 Hz
● N3224PX-ON: 100–240 VAC 50/60 Hz
● N3248TE-ON: 100–240 VAC 50/60 Hz
● N3248P-ON/E3248P-ON: 100–240 VAC 50/60 Hz
● N3248X-ON: 100–240 VAC 50/60 Hz
● N3248PXE-ON/E3248PXE-ON: 100–240 VAC 50/60 Hz
Maximum current draw per system
● N3208PX-ON: 7A@110VAC and 3.5A@220VAC
● N3224T-ON: 7A@110VAC and 3.5A@220VAC
● N3224F-ON/E3224F-ON: 7A@110VAC and 3.5A@220VAC
● N3224P-ON: 7A@110VAC and 3.5A@220VAC
● N3224PX-ON: 17A@110VAC and 3.5A@220VAC
● N3248TE-ON: 7A@110VAC and 3.5A@220VAC
● N3248P-ON/E3248P-ON: 7A@110VAC and 3.5A@220VAC
● N3248X-ON: 7A@110VAC and 3.5A@220VAC
● N3248PXE-ON/E3248PXE-ON: 7A@110VAC and
3.5A@220VAC
Maximum power consumption without PoE
● N3208PX-ON: 107 W @ 54 VDC
● N3224T-ON: 201 W @ 54 VDC
● N3224F-ON/E3224F-ON: 224 W @ 54 VDC
● N3224P-ON: 224 W @ 54 VDC
● N3224PX-ON: 340 W @ 54 VDC
● N3248TE-ON: 212 W @ 54 VDC
● N3248P-ON/E3248P-ON: 237 W @ 54 VDC
● N3248X-ON: 480 W @ 54 VDC
● N3248PXE-ON/E3248PXE-ON: 554 W @ 54 VDC
Specifications 81
