Dell PowerVault ME5 Series User Manual

Table 1. 2U12 enclosure variants (continued)
Product Configuration PCMs
1
Controller modules and IOMs
2,3
ME412 12 Gb/s direct dock SAS drives 2 2
1
The redundant PCMs must be compatible modules of the same type.
2
The supported controller modules are 4-port FC SFP+, 4-port iSCSI SFP28, 4-port 10Gbase-T iSCSI, 4-port mini-SAS HD. The
supported IOMs are used in expansion enclosures for adding additional storage.
3
In single-controller module configurations, the controller module is installed into slot A, and a controller blank is installed in slot
B.
2U24
2U24 enclosures consist of 24 SFF (Small Form Factor) disk drives.
Table 2. 2U24 enclosure variants
Product Configuration PCMs
1
Controller modules or IOMs
2,3
ME5024 12 Gb/s direct dock SAS drives 2 2
12 Gb/s direct dock SAS drives 2 1
ME424 12 Gb/s direct dock SAS drives 2 2
1
The redundant PCMs must be compatible modules of the same type.
2
The supported controller modules are 4-port FC SFP+, 4-port iSCSI SFP28, 4-port 10Gbase-T iSCSI, 4-port mini-SAS HD. The
supported IOMs are used in expansion enclosures for adding additional storage.
3
In single-controller module configurations, the controller module is installed in slot A, and a controller module blank is installed
in slot B.
5U84
5U84 enclosures consist of 84 LFF, or 84 SFF disk drives held in two 42-slot drawers.
Table 3. 5U84 enclosure variants
Product Configuration PSUs
1
FCMs
2
Controller modules or IOMs
3
ME5084 12 Gb/s direct dock SAS drives 2 5 2
ME484 12 Gb/s direct dock SAS drives 2 5 2
1
The redundant PCMs must be compatible modules of the same type (both AC).
2
The fan control module (FCM) is a separate CRU (not integrated into a PCM).
3
The supported controller modules are 4-port FC SFP+, 4-port iSCSI SFP28, 4-port 10Gbase-T iSCSI, 4-port mini-SAS HD. The
supported IOMs are used in expansion enclosures for adding additional storage.
2U enclosure core product
The design concept is based on an enclosure subsystem together with a set of plug-in modules.
The following figures show component locations—together with CRU slot indexing—relative to 2U enclosure front and rear
panels.
Storage system hardware
11

Dell PowerVault ME5 Series Specifications

General

Form Factor	2U or 5U
RAID Levels	RAID 0, 1, 5, 6, 10
Drive Types	SSD
Max Drives	336
Controllers	Dual active-active controllers
Host Connectivity	FC, iSCSI, SAS
Management	Dell EMC PowerVault Manager
Power Supply	Dual redundant hot-swappable power supplies
Operating Temperature	5°C to 35°C (41°F to 95°F)
