Installing the battery
NOTE
: the 92Whr battery requires the use of a M.2 card and a 68Whr battery can be used with either a M.2 or 7mm SATA drive.
1 Insert the battery into the slot on the laptop.
NOTE
: Route the battery cable below the battery routing channels to enable proper connection to the connector.
2 Connect the battery cable to the connector on the system board.
3 Tighten the M2.5x5 screw (2) to secure the battery to the laptop.
4 Install the base cover.
5 Follow the procedure in After working inside your computer.
Solid State Drive — optional
Removing the M.2 Solid State Drive - SSD
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
3 To remove the SSD:
a Remove the one M2x3 screw [1] that secures the SSD bracket to the laptop and lift the SSD frame [2] that secures the SSD
card to the system board. .
b the SSD that secures the SSD card to the system board .
Disassembly and reassembly
17
