Installing the display back cover assembly
1 The display back cover assembly is the remaining component, after removing all the components.
2 Install the:
a camera
b eDP cable
c display panel
d display bezel
e display assembly
f WWAN card
g WLAN card
h battery
i base cover
3 Follow the procedure in After working inside your computer.
Palm rest
Replacing the palm rest
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
c keyboard
d WLAN card
e WWAN card
f SSD card
g memory module
h Touchpad
i heat sink
j coin cell battery
k chassis frame
l system board
m hinge cap
n display assembly
NOTE
: The component you are left with is the palm rest.
54 Disassembly and reassembly
