Dell Precision 3530 User Manual

Installing the power connector port
1 Insert the power connector port into the slot on the laptop.
2 Place the metal bracket on the power connector port.
3 Tighten the M2x3 screw to secure the metal bracket to the power connector port on the laptop.
4 Connect the power connector port cable to the connector on the system board.
5 Install the:
a battery
b base cover
6 Follow the procedure in After working inside your computer.
Chassis frame
Removing the chassis frame
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a SIM card module
b base cover
c battery
d WLAN card
e WWAN card
30
Disassembly and reassembly

Dell Precision 3530 Specifications

General

Bluetooth	Bluetooth 5.0
Processor	8th Generation Intel Core i5/i7
Graphics	Intel UHD Graphics 630 or NVIDIA Quadro P600
Display	15.6" FHD (1920 x 1080)
RAM	Up to 32GB DDR4 2666MHz
Storage	Up to 2TB HDD or up to 1TB SSD
Operating System	Windows 10 Pro, Ubuntu
Battery	4-cell 68Whr
Ports	RJ-45, SD card reader
Wireless	Intel Dual Band Wireless-AC
