Dell Precision M6500 - Flash Cache Module (FCM)

Back to Contents Page
Flash Cache Module (FCM)
DellPrecision™WorkstationM6500ServiceManual
Removing the FCM Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the access panel.
4. Remove the screw that secures the FCM card to the system board.
5. Pull the FCM card away from the computer.
Replacing the FCM Card
To replace the FCM card, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
