Hinge Cover
DellPrecision™WorkstationM6500ServiceManual
Removing the Hinge Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Starting from the left edge, gently pry the hinge cover away from the computer.
4. Flip the hinge cover over and place it on the keyboard.
5. Disconnect the cables that connect the hinge cover to the computer.
6. Remove the hinge cover from the computer.
Replacing the Hinge Cover
To replace the hinge cover, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
