Wireless Wide Area Network (WWAN) Card
DellPrecision™WorkstationM6500ServiceManual
Removing the WWAN card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the access panel.
4. Disconnect the antenna cables from the WWAN card.
5. Remove the screw that secures the WWAN card to the system board. The card pops up at a 45-degree angle.
6. Slide the WWAN card out of the connector on the system board.
Replacing the WWAN Card
To replace the WWAN card, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
